Teltonika COMBO MIMO MOBILE/GNSS/WIFI ROOF SMA ANTENNA [PR1KCO28]

Teltonika COMBO MIMO MOBILE/GNSS/WIFI ROOF SMA ANTENNA (PR1KCO28)

Features

GNSS ANTENNA

Frequency range

1575 ~ 1610 MHz

Polarization

RHCP

Impedance

50 Ω

LNA gain

28 ± 2 dB

LNA noise figure

1.5 dB

Supply voltage

3.0 – 5.0 VDC

Current consumption

15 mA

LNA VSWR

2.0

Connector type

SMA Male

LTE MIMO ANTENNA

Frequency range

698 ~ 960, 1710 ~ 2690 MHz

Polarization

Linear

Gain

3.0 dBi

VSWR

3.0

Impedance

50 Ω

Connector type

2x SMA Male

WIFI MIMO ANTENNA

Frequency range

2400 ~ 2483, 4900 ~ 5825 MHz

Polarization

Linear

Gain

2.0 dBi

VSWR

2.5

Impedance

50 Ω

Connector type

2x RP-SMA Male

MECHANICAL/ENVIRONMENTAL

Mounting method

Screw

Radome ingress protection rating

IP65

Radome material

Black ABS

Housing dimensions

Ø 110 x 55 mm

Cable

5x RG174, 3000 mm

RoHS compliant

✓

Weight

550 g
